2000 Series UNx™


complex jobs.

compact solutions.

Built for Efficiency, The 2000 Series UNx™ Pump is compact and lightweight, measuring 28” L x 20” W x 10.5” H and weighing just 325 lbs with a UNx™ Fluid End installed.

Experience the Benefits of UNx™ Fluid Ends. Best in the industry, delivering a wide range of flow and pressure combinations, superior performance, greater flexibility in the field, and reduced downtime and maintenance.

Upgrade to the 2000 Series UNx™ Pump today to power your industrial cleaning application with the most compact and efficient pump in the industry!


2000 Series UNx Bareshaft Pump
Key Specs
  • Wide range of flow and pressure combinations
  • Three plunger (triplex) design
  • Plunger stroke length 2.00 in (50.8 mm)
  • Max Power Input 75 HP (120 kW)
  • 20 gpm at 6,000 psi (74.95 l/min at 414 bar)
  • 11.6 gpm at 10,000 psi (44 l/min at 690 bar)
  • 7.7 gpm at 15,000 psi (29.1 l/min at 1034 bar)
  • 5.28 gpm at 22,000 psi (20 l/min at 1500 bar)
  • Max Frame Load 13,000 lb
  • Total weight 325lb (147 kg)
  • Pump Oil Capacity 1 gal (3.8 L)
Key Features



  • Quickly change between pressures in the field with different Jetstream UNx™ Fluid End packages
  • Reduced downtime and maintenance with quick change packing and valves
  • American sourced components
  • Ductile iron power frame is the strongest in the industry
  • Crankshaft machined from high-tech forged alloy for superior performance at higher power input
  • Largest bearings of any comparable pump on the market
